Diamond S is a strong cationic resin. Compared with SP Bestarose FF, it has a higher dynamic capacity at high flow velocity. The resin used for the resin is highly cross-linked rigid agarose, which can be adapted to high flow velocity operation, and its physical and chemical properties are stable. During purification and cleaning regeneration, the resin load and various properties are not affected by external buffers. The impact is more suitable for large-scale industrial production. Diamond S has the following characteristics:
High flow velocity, large volume of processing capacity, short operation cycle, improve productivity
High rigidity matrix, high pressure resistance
Appearance |
White slurry, can be layered |
Matrix |
High rigidity agarose containing dextran long chain |
Functional group |
Sulfomethyl |
Average Particle size+ |
~90μm |
Max. pressure |
0.5MPa |
Pressure flow velocity |
≥1500cm/h(0.5MPa BXK 100/500 H=20 cm 20℃) |
Ionic capacity |
110~140μmol H+/mL packed resin |
Dynamic binding capacity |
>60mg β - lactoglobulin/mL packed resin >120mg lysozyme/mL packed resin |
Chemical stability |
Stable in common aqueous buffers: 1M NaOH++,0.1M NaOH,1M HCl, 6M GuHCl,8M Urea,70% ethanol,20% ethanol, 0.2M NaAc + 20% ethanol ,30% isopropanol Avoid contact with oxidizing agents, cationic detergents. Avoid long time exposures (1 week, 40℃)to pH <3. |
pH stability |
4~12(working) , 3~14(CIP) |
Operating temperature |
Working temperature:2~40℃, do not freeze. |
Storage+++ |
2~30℃, 20% ethanol with 0.2M NaAc or 2% benzyl alcohol with 0.2M NaAc |
Recommended flow velocity |
90~500cm/h |
+ Average particle size is the accumulated resin particle size of packing volume distribution.
++1M NaOH only be used for cleaning.
+++2% benzyl alcohol is only used for international transport or special requirements from customer.
Product |
Cat. No. |
Pack size |
Diamond S |
AI0181 |
25mL |
AI0182 |
100mL |
|
AI313311 |
500mL |
|
AI0183 |
1L |
|
AI0184 |
5L |
|
AI0185 |
10L |
|
AI313315 |
20L |
|
AI313316 |
40L |
Prepacked columns |
Cat. No. |
Pack size |
EzFast Diamond S |
EI01821 |
1×1mL |
EI313351 |
5×1mL |
|
EI313303 |
1×5mL |
|
EI313353 |
5×5mL |
|
EzScreen Diamond S |
EI01825 |
1×4.6mL |
EI01835 |
5×4.6mL |
|
EzLoad 16/10 Diamond S |
EI313304 |
1 pcs |
EzLoad 26/10 Diamond S |
EI313306 |
1 pcs |
